In this last part of this article we will illustrate another interesting 3d modeling software for the realization of Anime: Rokkaku.

Rokkaku: a quick guide

Let's see what the captions of Menu in Rokkaku mean...

I recommend Rokkaku too.
It is a very interesting software. It does not have many feature, but only about modeling, this soft is not behind anyone on the commercial. Well, now we'll try to make a tutorial of Rokkaku in English. :) ...

Draw left-right symmetrical objects

at first draw left-right symmetrical objects on the screen.

Line tool [ ]
Add Points -Click
Line End -Dobble Click
Redo - Bs Key or R click

3D manga feature

Turn [ ]
3D model is automaticaly created from that picture when you change angle.

Click - turn
Click + Shift - Turn

Improve

at the Front Top or Left angle ,models are displayed in Ortho projection.
from those angle , improve the 3D Shapes.

Select and Move [ ]

Click - Select single
select the point and Drag - Move
Drag - select range

Click + Shift - Select with drag

Hide lines

Not to be prevented,We can hide selected lines
by menu " (H)" (Ctrl +H )

Hided lines
It is not selected by select tool [ ].
And without CTRL key , it can not fasten line to the hided vertex too.

Draw again

Line tool [ ]
Click+CTRL key - fasten line to the hided vertex

Show all lines

Hided line is not selected by select tool.
But It can be selected by "menu Edit- select all (CTRL+A)"

then , Hided line is showed by " (S)"menu " (S)"

Create Faces

create lines more to make triangles and rectangles.
because Polygon is created on triangle and rectangle by
Menu" "-" " Ctrl+B

Make in detail.

If you want to add a vertex on the line
then you can use Line tool or Select tool pushing alt key.

[ ] [ ]


Click + Alt key - add vertex on the line

At the Parts which is difficult to be made by 3D Manga feature.
It have better to create Shapes by "??(S)"menu "??(F)"

Paint the faces

In this way, create the model
and then, Paint the object by Paint tool

Paint tool [ ]

Finally, our head 3d model finished!

Soredewa!! (^o^)/

Takaya Satoshi
